PR Series（10A）
Safe and reliable performance, standard with mechanical indicators and LED lights, ideal for communication, automatic control, mechatronics, and power electronics.
-
Rated Insulation Voltage
250V
-
Rated Impulse Withstand Voltage
6000V
-
Rated Thermal Current
PR2K/PR2KLT/PR3K/PR4K：10A
-
Degree Of Protection
IP40
Product Features
Technical Parameters
Main Parameters
|
Number and Type of Contact Pole |
2C/O changeover contact, 3C/O changeover contact, 4C/O changeover contact |
|
Contact Material |
Silver alloy |
|
Rated Thermal Current |
10A |
|
Compliance Standards |
GB/T 21711.1、IEC61810-1 |
|
Certificate |
UL/CQC/CE |
|
Ambient Temperature |
Storage: -40°C to +85°C, no icing or condensation Operation: -25°C to +55°C, no icing or condensation |
|
Ambient Humidity |
Storage: 5~85%RH (no condensation) Operation: 5~85%RH (no condensation) |
|
Degree of Protection |
IP40 |
|
Rated Insulation Voltage |
250V |
|
Insulation Resistance |
100MΩ |
|
Rated Impulse Withstand Voltage |
2500V |
|
Vibration Resistance |
10-55Hz, double amplitude 1.0mm |
|
Impact Resistance |
Operating state 200m/s2 and non-operating state 100m/s2, 11ms |
|
Pull-in Time |
≤20ms |
|
Release Time |
≤20ms |
|
Power Frequency Withstand Voltage |
AC 5000V 50Hz·1min |
|
Electrical Endurance |
1.2×10? times / 1.0×10? times |
|
Mechanical Endurance |
1.0×10? times |
|
Weight |
35g/50g/60g |
|
Min. Package Quantity |
20pcs/10pcs |
