SR Series（8A）
Compact size, large capacity, safe and reliable performance, standard with mechanical indicators, ideal for communication, automatic control, mechatronics, and power electronics
-
Rated Insulation Voltage
250V
-
Rated Impulse Withstand Voltage
6000V
-
Rated Thermal Current
SR2H/SR2HLT：8A
-
Degree Of Protection
IP40
Product Features
Technical Parameters
Main Parameters
|
Number and Type of Contact Pole |
Changeover contact |
|
Contact Material |
Silver alloy |
|
Rated Thermal Current |
8A |
|
Compliance Standards |
GB/T 21711.1 IEC 61810-1 |
|
Certificate |
UL/CQC/CE |
|
Ambient Temperature |
Storage: -40°C to +85°C, no icing or condensation Operation: -40℃~+70℃, no icing or condensation |
|
Ambient Humidity |
Storage: 5~85%RH (no condensation) Operation: 5~85%RH (no condensation) |
|
Degree of Protection |
IP40 |
|
Rated Insulation Voltage |
250V |
|
Insulation Resistance |
1000MΩ |
|
Rated Impulse Withstand Voltage |
6000V |
|
Vibration Resistance |
1-55Hz, double amplitude 1.5mm |
|
Impact Resistance |
Operating state 200m/s2 and non-operating state 100m/s2, 11ms |
|
Pull-in Time |
≤20ms |
|
Release Time |
≤15ms |
|
Power Frequency Withstand Voltage |
AC 5000V 50Hz·1min |
|
Electrical Endurance |
1.0×10? (Frequency: 1,800 times/hour) |
|
Mechanical Endurance |
1.0×10? (Frequency: 18,000 times/hour) |
|
Weight |
Approx. 20g |
|
Min. Package Quantity |
20pcs |
2D/3D Drawings
Industry Application
-
MarineAPT products are used to measure,control or indicate the electrical equipment on ships for safety and reliability even in harsh conditions.The products include cam switches, indicators, MCBs, current transformers, etc.
-
Electric elevatorAPT products offer stable control and indication for electric elevators, ensuring their safe and stable operation. The products include cam switches, indicators, MCBs, relays,pushbutton,pushbutton boxes etc.
